Nvidia GeForce GTX 1050 Ti PCB Pictured, Rumored to Launch October 26

Sam ChenOctober 3, 2016

nvidia-geforce-gtx-1050-ti-colorful-leaked-pcb-image-3

Several days ago, GPUz specifications and 3D Mark benchmarks for the Nvidia’s upcoming GeForce GTX 1050 Ti were leaked in the Baidu forums and today, images of the PCB have leaked online as well.

Images of the PCB confirm a number of rumored details and specifications of the GeForce GTX 1050 Ti. As we see in the above image, the GPU powering the upcoming graphics card will be the GP107 GPU which will sport 768 CUDA cores as we’ve seen in previous rumors. The GPU is most likely being produced by Samsung’s 14nm process which was reported earlier this year.

The same GPU is also expected to be used in the GeForce GTX 1050, except it will be cut down to just 640 CUDA cores. Here we can see 4 memory packages which appear to be Samsung branded. The GeForce GTX 1050 Ti is expected to contain 4GB of VRAM while the GeForce GTX 1050 will only get 2GB. This specific card also appears to contain a 3+1 phase power delivery system.

nvidia-geforce-gtx-1050-ti-colorful-leaked-pcb-image

The rear of the card makes it pretty clear what we’re looking at. Although there’s quite a bit of Chinese, we can clearly see GTX 1050Ti – 4GD5, so GTX 1050 Ti with 4GB of GDDR5.

nvidia-geforce-gtx-1050-ti-colorful-leaked-pcb-image-2

At the top right hand corner of the PCB we can see a single 6-pin power connector. The GeForce GTX 1050 Ti card is rumored to be rated at just 75W TDP, so it should just run off bus power just fine however, this may just be for additional overclocking capacity.

The GeForce GTX 1050 is rumored to launch on October 18 while the GeForce GTX 1050 Ti is rumored to launch on October 26. Prices are expected to be somewhere in the $165-$180 range for the GeForce GTX 1050 Ti and $135-$150 range for the GeForce GTX 1050.



Source: Baidu via VideoCardz
